The GG/DH is the downhill workhorse, built for serious riders that prefer a refined machine that is built to last, likes goin' fast, and is made in the good ol' US of A.
It's the bike for the those that like to get out and ride day in and day out, for riders that want something that's high performance, but easy to maintain. With a highly refined design that eliminates all unnecessary complication, the suspension platform is progressive and the frame laterally stiff. The geometry is low, slack, and adjustable. The ride characteristics provide a lively, nimble platform that pedals extremely well for its shred-tastic capabilities.
Don't forget, all Guerrilla Gravity frames and bikes come with access to the GG Rider Program.
Please email us at Bikes@RideGG.com with any questions about the frame, shipment, or payment!
Frame Info & Specs:
- Rear Wheel Travel 8", 9.5" x 3.0" Shock
- Progressive Leverage Curve - No Blowing Through the Travel or Harsh Top Stroke Here!
- 1.5" Head Tube, Cane Creek Angleset Compatible
- Adjustable Chainstay Length via Axle Mount
- Adjustable Head Angle/BB Height via Shock Mount
- Designed With Frame Stiffness in Mind
- Massive 25mm Pivot Axle
- Zero Free Play Pivot and Axle Interfaces
- High quality Enduro dual-lip sealed bearings
Frame weight: 7.9 lbs. with hardware (size Medium, no shock)
Frame Geometry:
- Chainstay, Adjustable: 17" or 17.5"
- Head Angle, Low: 63.5 deg.
- BB Height, Low: 13.4"
- Head Angle, High: 64.2 deg.
- B Height, High: 13.9"
Small:
- Reach: 15.5"
- Effective Top Tube: 23.35"
- Wheelbase, Adjustable: 46.75" or 47.25"
Medium:
- Reach: 16.25"
- Effective Top Tube: 24.1"
- Wheelbase, Adjustable: 47.5" or 48"
Large:
- Reach: 17"
- Effective Top Tube: 24.85"
- Wheelbase, Adjustable: 48.25" or 48.75"
* Please note: Final wheelbase is dependent on fork offset and travel. These wheelbase numbers are calculated with a Manitou Dorado, which has 49.5 mm offset.
Sizing Recommendations:
- Small: 5'4" - 5'9"
- Medium: 5'9" - 6'1"
- Large: 6'1" - 6'6"
Frame fittings:
- 30.9 seatpost
- 34.9 seatpost clamp
- ISCG05 chainguide tabs
- 150 mm rear wheel spacing
- 83 mm BB spacing
